18? Live X Subwoofer

Description

Optimized for performance with the ELX112 and ELX115, the ELX118 adds a full, deep, low-frequency punch that you can hear and feel.

Axial Sensitivity: 96 dB
Case Material: 9-ply, 15mm Plywood, Internally Braced, with Texured Paint
Frequency Response: (-3 dB) 50 Hz – 100 Hz Hz
Frequency Response: (-10 dB) 35 Hz – 200 Hz Hz
Recommended High-Pass Frequency: 30 Hz
Max. SPL/1m (calc): 134 dB
Coverage (Nominal -6 dB) H: Omnidirectional ?
Coverage (Nominal -6 dB) V: Omnidirectional ?
LF Transducer: (1) EVS-18K, 457mm (18″) Woofer
HF Transducer: N/A
Crossover Frequency: N/A Hz
Nominal Impedance (Passive): 8
Minimum Impedance: 6.7
Connector Type: Dual NL4
Grill: 18GA Steel with Black Powdercoat
Height: 661 mm (26.02″)
Width: 507 mm (19.96″)
Depth: 574 mm (22.6″)
Weight Net: 31.8 kg (70.11 lbs)
Shipping Weight: 35.4 kg (78.04 lbs)
