1080P FHD HDMI to 3G-SDI Long Distance Converter/Amplifier
$49.00
Description
The BG-H3GS allows HDMI signals to be shown on SDI displays while ensuring a high bit rate of 2.970 Gbit/s to provide a high-resolution signal without any loss. For professionals this means that it is now easier to convert your high-definition HDMI signal with audio to SDI for long distance transmissions and display your work on SDI displays.
The BG-H3GS supports multiple input resolutions such as 480i, 720p, 1080i, and up to 1080p60. A 1080p60 HDMI signal will convert to 3G-SDI for transmission up to 100m (328ft). For even longer range transmissions 480i will convert to SD-SDI and can be transmitted up to 300m (984ft).
Features
- 1080p/60 Support Crystal clear images with resolutions up to 1080p@60Hz
- Portable Ideal for any on-the-go kit
- Rigid Design Durable metal structure built to withstand years of operation
- 3G-SDI – Up to 100 meters, HD-SDI – Up to 200 meters, SD-SDI – Up to 300 meters
- HDMI input timings: [email protected], 576i, 720p@50/59.94/60, 1080i@50/59.94/60, [email protected]/24/25/29.97/30/50/59.94/60
- SDI Transmission Rate – 2.970 Gbit/s and 2.970/1.001 Gbit/s
Additional information
| Weight | 1 lbs |
|---|---|
| Dimensions | 6 × 4 × 2 in |
